2020 Mazda CX-30 Specifications – Learn More Here!

Here is your chance to learn the ins and outs of the 2020 Mazda CX-30. Keep reading for all the details!

ENGINE & MECHANICAL

• BORE X STROKE (MM) – 89.0 x 100.0
• REDLINE – 6500 rpm
• ENGINE BLOCK – Aluminum alloy
• EMISSION CONTROL (50 STATE EMISSIONS) – SULEV30
• CYLINDER HEAD – Aluminum alloy
• COMPRESSION RATIO – 13.0 : 1
• OIL TYPE – OW-20
• RECOMMENDED FUEL – Regular unleaded
• FUEL SYSTEM – Advanced Direct Injection
• ENGINE TYPE – SKYACTIV®-G 2.5L DOHC 4-cylinder with VVT
• HORSEPOWER – 186 hp @ 6000 rpm
• TORQUE – 186 lb-ft @ 4000 rpm
• DISPLACEMENT (CC) – 2488
• VALVETRAIN – 4 valves per cylinder with variable valve timing (VVT)
• SKYACTIV-VEHICLE DYNAMICS WITH G-VECTORING CONTROL PLUS

EPA-ESTIMATED FUEL ECONOMY

• FWD, AUTOMATIC TRANSMISSION(CITY/HWY/COMBINED) – 25 / 33 / 28
• AWD, AUTOMATIC TRANSMISSION(CITY/HWY/COMBINED) – 24 / 31 / 26

DRIVETRAIN

• TYPE – Front-wheel drive (FWD) or i-ACTIV AWD® with Off-road Traction Assist
• AUTOMATIC TRANSMISSION – SKYACTIV®-DRIVE 6-speed electronically controlled sport automatic transmission
• GEAR RATIOS (:1) – 6 AT
• 1ST – 3.552
• 2ND – 2.022
• 3RD – 1.347
• 4TH – 1.000
• 5TH – 0.745
• 6TH – 0.599
• REVERSE – 3.052
• FINAL DRIVE – 3.626 (3.850 AWD)

CHASSIS

• BRAKES – 4-wheel disc
  • FRONT – 11.6-inch vented disc
  • REAR – 10.4-inch solid disc
  • ABS – 4-wheel, 4-channel with Electronic Brake Force Distribution and Brake Assist
• STEERING – Rack-and-Pinion Electric Power Assist Steering (EPAS)
• TURNING CIRCLE DIAMETER, WALL TO WALL (FT) – 37.3
• FRONT SUSPENSION – Independent MacPherson strut
• REAR SUSPENSION – Torsion beam axle
• WHEEL SIZE (IN) – 16-inch aluminum alloy wheels
• TIRE SIZE – P215/65R16 all-season tires
• TEMPORARY SPARE TIRE – T135/80D 17

EXTERIOR DIMENSIONS

• WHEELBASE (IN) – 104.5
• TRACK, FRONT (IN) – 61.6
• TRACK, REAR (IN) – 61.6
• LENGTH, WITH LICENSE PLATE HOLDER (IN) – 173.0
• WIDTH (IN) – 70.7
• HEIGHT (IN) – 61.7
• MINIMUM GROUND CLEARANCE, UNLADEN (IN) – 6.9

EXTERIOR FEATURES

• LED Headlights
• Auto on/off headlights
• LED combination tail lights
• LED Daytime Running Lights
• Body-colored folding power side mirrors
• Rain-sensing variable-intermittent windshield wipers
• Front grille in matte finish

INTERIOR DIMENSIONS & CAPACITIES

• HEADROOM, FRONT/REAR (IN) – 38.1 / 38.3
• SHOULDER ROOM, FRONT/REAR (IN) – 55.6 / 53.6
• HIP ROOM, FRONT/REAR (IN) – 54.6 / 53.2
• LEGROOM, FRONT/REAR (IN) – TBD / 36.3
• EPA PASSENGER VOLUME WITHOUT MOONROOF (CU FT) – 94.1
• EPA CARGO VOLUME (2ND ROW SEATS UP, CU FT) – 20.2

COMFORT & CONVENIENCE

• Air conditioning
• Power windows with one-touch up/down feature
• Push button start
• Power door locks – speed sensitive auto door locks
• Steering-wheel-mounted audio and cruise control switches
• Remote keyless entry system
• Electronic parking brake
• Vinyl-covered sun visors with extensions
• 12-volt power outlet
• Front map lights and cargo area light

STORAGE

• Glove compartment
• Front center console armrest with covered storage compartment
• Front door storage pockets with bottle holders
• Front passenger-side seat-back pocket

SEATING & TRIM

• 5-passenger seating
• 60/40 split fold-down rear seatback
• Cloth-trimmed sport seats and door inserts
• Adjustable headrests in all seating positions

AUDIO & INFOTAINMENT

• 8-speaker audio system with Mazda Harmonic Acoustics
• Bluetooth® hands-free phone and audio streaming capability
• MAZDA CONNECT™ Infotainment System
• 8.8-inch center display
• Mobile 911 automatic emergency notification
• HD Radio™
• Infotainment system voice command
• Multifunction Commander control
• Pandora® internet radio integration
• Radio Broadcast Data System program information
• SMS text message audio delivery and reply
• Mazda Connected Services
• 2 USB audio inputs

INSTRUMENTATION

• 7-inch LCD Meter Display
• Trip odometers, resettable
• Trip computer, current and average fuel economy, distance-to-empty

SAFETY & SECURITY

• Advanced dual front air bags
• Anti-lock Brake System with Electronic Brake Force Distribution & Brake Assist
• 3-point safety belts for all seating positions
• Front seat-mounted side-impact airbags and side-impact air curtains
• Dynamic Stability Control with Traction Control System
• Front safety-belt pretensioners with force limiters
• Driver’s and front passenger’s knee airbags
• Whiplash-reducing front seat headrests
• Smart Brake Support
• Rearview camera
• Tire Pressure Monitoring System (TPMS)
• Driver Attention Alert
• Lane Departure Warning
• Engine-immobilizer antitheft system
• LATCH child safety seat anchors & upper tethers
• High Beam ControlLane-keep Assist
• Mazda Radar Cruise Control with Stop & Go
• Keyless remote panic button (on key fob)
• Child safety rear door locks
